5 Hz – 10 kHz (Acceleration)
10 Hz – 1 kHz (Velocity)*
10 Hz – 150 Hz (Displacement)*
1 kHz – 10 kHz (Bearing)
3 Hz – 1 kHz (H-function)

* Maximum frequency of velocity and displacement is restricted by acceleration limit 450 m/s2.

10 Hz – 1 kHz
(Acceleration, velocity and displacement )

0.3 Hz – 100 Hz
(Acceleration)*
3 Hz – 100 Hz
(Velocity and displacement)

* Maximum frequency of velocity and displacement is restricted by acceleration limit 20 m/s2.

Full scale

acceleration, velocity, displacement :
6 range, automatic switching
bearing :
6 range, automatic switching
H function :
6 range, automatic switching

Acceleration :
6 Range, Automatic Switching
Velocity :
6 Range, Automatic Switching
Displacement :
6 Range, Automatic Switching

Acceleration :
6 Range, Automatic Switching
Velocity :
6 Range, Automatic Switching
Displacement :
6 Range, Automatic Switching

Maximum
mesurable range

acceleration, H function :
300 m/s² (RMS,EQP,PEAK)
velocity : 1000 mm/s (RMS, EQP, PEAK)
displacement :10 mmp-p (EQP, PEAK)

acceleration :
100 m/s² (RMS,EQP,PEAK)
velocity :
200 mm/s (RMS, EQP, PEAK)
displacement :
1000 μmp-p (EQP,PEAK)

acceleration :
20 m/s² (RMS, EQP, PEAK)
velocity :
100 mm/s (RMS, EQP, PEAK)
displacement :
10 mmp-p (EQP, PEAK)

Indication

PEAK :
acceleration, velocity, displacement
EQP :
acceleration, velocity, displacement
RMS :
acceleration, velocity

PEAK :
acceleration, velocity, displacement
EQP :
acceleration, velocity, displacement
RMS :
acceleration, velocity

PEAK :
acceleration, velocity, displacement
EQP :
acceleration, velocity, displacement
RMS :
acceleration, velocity

Frequency
response

±5% (10 Hz – 5 kHz)
＋30% / -50% (5 Hz – 10 Hz, 5 kHz – 10 kHz)

±5% (20 Hz – 500 Hz)
+5% / -15% (10 Hｚ-20 Hz, 500 Hz-1 kHz)

±5% (0.3 Hz – 100 Hz)

Sensitivity error

±5%
(for full scale value at 1 kHz)

±5%
(for full scale value at 80 Hz)

±5%
(for full scale value at 16 Hz)

Range changeover error

±2% (1 kHz standard)

±2% (80 Hz standard)

±2% (16 Hz standard)

Output

AC OUT：
0 – ±1 V (Load 10 kΩ or higher)
DC OUT：
0 – +1 V (Load 10 kΩ or higher)

AC OUT：
0 – ±1 V (Load 10 kΩ or higher)
DC OUT：
0 – +1 V (Load 10 kΩ or higher)

AC OUT：
0 – ±1 V (Load 10 kΩ or higher)
DC OUT：
0 – +1 V (Load 10 kΩ or higher)

Language

Japanese, English (Switching)

Japanese, English (Switching)

Japanese, English (Switching)

Size / Mass of
body unit

74 (W)×32.5 (D)×148 (H) mm
approx.230 g (including battery)

74 (W)×32.5 (D)×148 (H) mm
approx.230 g (including battery)

74 (W)×32.5 (D)×148 (H) mm
approx.230 g (including battery)
